Mitsubishi 276P595010 DLP Chip Replacement for DLP TV RepairHow to Replace DLP Chip in Mitsubishi TV Repair TutorialBe sure to unplug your TV before starting any repairs.Unscrew and remove the bottom panel from the back of your TV.Remove all cables from the light engine.Take care not to use excessive force when removing cables.Exact locations of cables will vary depending on TV.Remove the screws holding the light engine in place.Carefully remove the light engine from the TV.Remove the lens shroud by removing the corresponding screws.Take care not to touch the lens.Remove all cables from the DMD board.Remove the DMD board housing screws.Remove the back half of DMD board housing from the bottom.Remove the DMD board screws.Make sure to support the board as you remove the final screws.Remove the DMD board from the light engine.Release the DLP chip heatsink by removing the corresponding screws.Remove the heatsink.Remove any remaining DMD board screws.Remove the DMD board from the front housing.Unlock and remove the DLP chip from the DMD board.Before installing the new DLP chip, please verify that it is equivalent in appearance to the original DLP chip,and that all part numbers are compatible.Compatible part numbers are listed on all relative ShopJimmy product pages.Remove all fingerprints and dust from the glass surface with a clean microfiber cloth.Install and lock your new DLP chip.Reinstall the DMD board into the front half of the housing.Reinstall the DLP chip heatsink.Reinstall DMD board onto the light engine.Reinstall the back half of the DMD board housing.Reinstall all DMD board cables on the lens side.Take care not to damage any cables when reinstalling.Reinstall the lens shroud.Before reinstalling the light engine into your tv,please take a moment to verify all surfaces especially near the lens are clean and free of dust.Carefully place the light engine back into the TVand secure it with the corresponding screws along the bottom.Reinstall all light engine cables.Take care not to damage any cables when reinstalling.Reinstall the bottom panel on the back of your TV.Your ShopJimmy replacement DLP chip does not need any manual configuration in order to function properly.Simply plug in your TV.wait for the green status light to stop blinking, power on,and your TV will function as if new.Should you notice a slight distortion to the angle of your picture along the edges,please check to make sure that your light engine and DMD board are flush and secure within their housings.
